50/6 Kab rov tav yeeb nkab Stranding tshuab

Spindle nrug: 42mm, 50mm, 57mm, 60mm, 72mm

Spindle ceev: Max 1000 ~ 12000rpm

Servo lub cev muaj zog: spindle: 750 ~ 1000W X-axis / Y-axis / Z-axis: 400W

Txoj kev pub mis: Kev pub mis rau kev thauj khoom thiab tshem tawm cov txheej txheem (tsis siv neeg pub mis tuaj yeem ntxiv)

Lub kaum sab xis: 360 degrees 1 lub voj voog, qhov chaw teeb tsa yog 0.1 degrees

Axis nres qhov tseeb: ntxiv lossis rho tawm 0.5 degrees

Siv tau txoj kab uas hla: 0.02mm-0.5mm

Qhov siab tshaj plaws txoj kab uas hla: 60mm

Qhov siab tshaj plaws: 80mm

Kev txav ntawm rab koob: X: 90mm Y: 90mm Z: 50mm

Koob ncej txav ceev: 260mm / sec

Qhia tus pin wrapping kaum sab xis: 0 degree, 90 degree, 120 degree

Taw khi ceev: Max 150 laps / min

Strand ntev: Max 480mm (adjustable)

Strands: 1,3,5… txhua qhov chaw

Stranding ceev: Max 6000rpm

Txoj kev tswj: AC Servo Tsav Synchronous Control

Txoj kev cia: RAM ntxiv rau FLASH cia, tsis muaj cov ntaub ntawv tsis ua haujlwm

Voltage: 220V, 50Hz

Kev siv hluav taws xob: 2 ~ 4KW

Compressed cua siab: 0 4-0.8MPa

Tshuab loj: 1000mm (L) * 900mm (W) * 1400mm (H)

Tshuab hnyav: 400KG

Lub npe: lub cev muaj zog, stator, inductor coil winding tshuab

Winder xaiv: Tsis siv neeg lagging, tsis siv neeg pub khoom noj, tsis siv neeg stranding tshuab, tsis siv neeg soldering, pneumatic txiab, yooj yim

Siv tau kauj: Synchronous motors, stepping motors, inductor coils, ntau yam transformer coils, I-shaped inductors, lim

nqe: Negotiable

muaj muag: National
