250/12 Kab rov tav yeeb nkab Stranding tshuab
Dav siv nyob rau hauv nruab nrab-loj coils xws li rectifiers, solenoid li qub, thiab high-power transformers.
Hauj lwm lawm
|
Teeb tsa kev npaj technology thiab kev tswj kom zoo |
||||||
|
Tus naj npawb |
Lub npe ntawm cov khoom yuav khoom |
Tag nrho qhov ntev |
qauv |
Tus naj npawb ntawm |
Qhov hnyav ntawm lub |
|
|
1 |
Kev kub ceev tube twister |
Dav 1000 * qhov siab 1300 * ntev 14800 |
12/250 |
5 200 KG |
||
|
Cov cuab yeej muaj pes tsawg leeg |
1, cov khoom siv yog tsim los ntawm Central Line, chim, tsim, traction, retracting kab, hluav taws xob tswj ib feem; |
|||||
|
Qhov project |
Tus naj npawb |
Khoom siv |
Cov kev xav tau muaj nuj nqi thiab cov khoom siv tsis tau |
ceeb toom |
||
|
Lub hauv paus ua haujlwm no tuaj yeem thiab ginseng |
1 |
Txoj kab uas hla ntawm hlau ua ntej twisting (mm) |
0.8 rau 2 |
|||
|
2 |
Tom qab twist (mm) |
2.5 ~ 5 |
||||
|
3 |
Twist range (mm) |
1-100 |
||||
|
4 |
Khoom siv ceev (RPM) |
Qhov siab tshaj plaws ceev 1800 RPM, ua hauj lwm ceev 1600 RPM, cov cuab yeej hloov ceev tuaj yeem teeb lo lus zais (PLC muaj nuj nqi tswj) |
||||
|
5 |
Kev Taw Qhia ntawm cov khoom siv |
Tig lub cuab yeej, cov hlau yog nyob rau sab xis |
||||
|
6 |
Twist kev taw qhia ntawm qhov system |
S/Z |
||||
|
7 |
Tube threading hom |
Txoj xov |
||||
|
8 |
Hlau hlau zog qib ntau (Mpa) |
600 ~ 2800 |
||||
|
9 |
Nres thaum lub ' meter ' tsim ua ntej mus txog |
Kev ntsuas ntsuas tau txais PLC tsis siv neeg nres rau ntsuas ntsuas, ntsuas qhov tseeb Tsawg dua lossis sib npaug li 1.5 feem pua. |
||||
|
10 |
Cov cuab yeej siv yuav tsum nres tsis siv neeg thaum pom cov kab tawg hauv thaj tsam ntawm lub tog raj kheej lub cev thiab nias tuag |
Cov cuab yeej muaj disconnection nres lub tswb ntaus ntawv. |
||||
|
11 |
LED teeb pom kev zoo yog ntsia hauv lub hau kev nyab xeeb |
Rau cov teeb pom kev tsis zoo thiab cov teeb ci, kev tiv thaiv kev nyab xeeb yuav tsum tau muab rau ntawm qhov chaw kom tsis txhob muaj kev sib tsoo ntawm lwm yam khoom thiab cov hlau hlau. |
||||
|
12 |
daim ntaub thaiv |
Txhua lub log I-wheel sib raug rau lub qhov rais saib. Lub qhov rais pom yog ua los ntawm cov iav toughened, thiab lub hau kev nyab xeeb yog hloov tau yooj yim qhib thiab nqis nrog seamless steel yeeb nkab. Lub tshuab tuaj yeem nres tam sim yog tias nws qhib Tsawg dua lossis sib npaug li 150mm. Thaum lub hau kev nyab xeeb qhib thiab tsis kaw, lub platform tsuas yog txav tau tab sis tsis tuaj yeem pib ib txwm. Lub suab nrov tshaj plaws yog 82dB kuaj ntawm qhov deb ntawm 1000mm los ntawm kev tiv thaiv npog |
||||
|
Tshem tawm cov kab nruab nrab |
Hom kev pub mis |
tsis tig |
||||
|
Kuv log jacking system |
Muaj hom ncej, bearing txhawb txhua yam nro kab. |
|||||
|
Lub damping system |
Siv tshwj xeeb hnav-resistant hlua caij nplooj ntoos hlav ntsia hlau hloov |
|||||
|
Txoj kab uas hla ntawm Tso Tawm I-log (mm) |
250 (raws li qhov xav tau ntawm I-wheel xav tau) |
|||||
|
Hauv lub tog raj kheej, lub log ua haujlwm lays txoj kab |
13 |
Kuv log jacking system |
Muaj hom ncej, bearing txhawb txhua yam tsis tu ncua tension paug, nro fluctuation tsawg dua 3N, nro ntau ntawm 30 ~ 80N. |
|||
|
14 |
Lub damping system |
Siv tshwj xeeb hnav-resistant hlua caij nplooj ntoos hlav ntsia hlau hloov |
||||
|
15 |
Txoj kab uas hla ntawm Tso Tawm I-log (mm) |
250 (raws li qhov xav tau ntawm I-wheel xav tau) |
||||
|
Lub tog raj kheej ntu |
16 |
Tus naj npawb ntawm I-wheels hauv txhua lub tog raj kheej |
3 * 4 knots =12 |
|||
|
17 |
Hom xaim system ntawm lub tog raj kheej |
Txhim kho cov kev taw qhia log ntawm txhua qhov khoov kom dhau txoj kab, thiab xyuas kom meej tias cov hlau hlau tsis plam thaum nteg tawm txoj kab. |
||||
|
18 |
Sab hauv txoj kab uas hla ntawm tungsten carbide nozzle rau txheej hlau routing |
Threading nozzle yog ua los ntawm cov khoom siv tawv alloy YG8 nrog ib txoj kab uas hla ntawm 8 hli. Nws yog tsau los ntawm cov ntsia hlau zawm thiab kua nplaum kom txhim khu kev qha. |
||||
|
19 |
Hlau qhov hluav taws xob Lub kaum sab xis ntawm hlau tais |
Lub kaum sab xis siab tshaj plaws los ntawm cov hlau nozzle ntawm qhov nruab nrab ntawm lub paj phaj mus rau cov hlau nozzle ntawm phab ntsa chim yuav tsum tsis pub tshaj 30 degree. Lub kaum sab xis siab tshaj plaws ntawm ob txoj kab tawg los ntawm lub qhov hluav taws xob ntawm lub qhov hluav taws xob ntawm thawj lub chim mus rau cov hlau nkag ntawm lub thoob kawg yuav tsum tsis pub tshaj 25 degree. Lub kaum sab xis siab tshaj plaws ntawm cov kab tawg los ntawm lub qhov hluav taws xob lub qhov hluav taws xob ntawm lub qhov hluav taws xob thib ob mus rau lub qhov hluav taws xob ntawm qhov sib faib disk yuav tsum tsis pub tshaj 25 degree. Tshwj xeeb alloy tuag yuav tsum tau muab ntsia rau ntawm qhov hluav taws xob los yog khoov kom ntseeg tau tias cov hlau hlau tsis plam los ntawm cov hlau tuag. |
||||
|
20 |
Lub tog raj kheej txhawb nqa bearing |
Cov kabmob loj |
Brand NSK |
|||
|
21 |
Lub tog raj kheej txhawb nqa loj bearing lubrication |
Roj lubricated, txhua tus kabmob yog ntsia rau ntawm lub rooj zaum, kev ua haujlwm kub tsawg dua lossis sib npaug li 75 degree |
||||
|
22 |
Bearing seat structure |
Hlau hlau.(QT - 400) |
||||
|
23 |
Phab ntsa thickness (mm) |
Tsis pub tsawg tshaj 12mm |
||||
|
24 |
Lub tog raj kheej system dynamic system |
Nres thiab nres xwm ceev yog qhov txawv. Kev nres ib txwm yuav tsum tau nres tom qab deceleration, uas tuaj yeem ua tiav los ntawm kev siv zog nres thiab lwm txoj hauv kev. Lub sijhawm nres nres nres yog tsawg dua 20 vib nas this, thiab nres thaum muaj xwm ceev yuav tsum ua kom tiav hauv 10 vib nas this. Nres ncoo tau yooj yim hloov tom qab hnav. |
||||
|
25 |
Hlau tais ncej I-log xauv |
Cov hlau phaj thav duab yog nruab nrog ncej bearing los txhawb ntsug tas li nro nteg tawm, thiab tsis siv neeg hloov nteg tawm nro ntaus ntawv los xyuas kom meej tias txhua steel hlau thiab strand nteg tawm tusyees. Damping nro ntsia hlau hloov rau txoj cai tes ua haujlwm. Txhua lub tais hlau tuaj yeem ua tau raws li qhov xav tau ntawm ø 250 I-log. |
||||
|
26 |
Kuv log bearing hom |
Kab rov tav txhawb kev xaim |
||||
|
27 |
Kuv log damping hauv hlau tais |
Tsis siv neeg hloov kho ntawm cov xov hlau nro, xyuas kom meej tias txhua tus hlau hlau, strand uniform kab. Kuv log ntawm txoj kab, damping siv ntsia lub caij nplooj ntoos hlav, damping nro ntsia hlau hloov kho rau txoj haujlwm sab xis. |
||||
|
28 |
Cov kab hluav taws xob ntes tau tawg |
Tswb kab tswb, PLC tswj qhov kev pab cuam. |
||||
|
29 |
Parallel lub tog raj kheej tsim |
Lub cev lub cev yog ib txoj kab sib txuas sab nraud, xyuas kom meej tias cov hlau xaim los ntawm qhov hluav taws xob ntawm lub thoob lub cev mus rau qhov kaw lub qhov ncauj ntawm cov xovxwm tuag zoo ib yam thiab tsis muaj qhov tshwm sim ntawm qhov hloov pauv, thiab qhov siab tshaj plaws folding lub kaum sab xis ntawm lub qhov hluav taws xob lub qhov ncauj. chim lub cev thiab lub qhov hluav taws xob lub qhov ncauj ntawm cov hlau phaj yuav tsum tsis txhob siab tshaj 25 degree. |
||||
|
30 |
Lub host base |
Tshooj steel plus steel plus pob zeb |
||||
|
31 |
Spindle tsav lub thawv |
Spindless tsav |
||||
|
Nyob rau hauv lub puab cheeb tsam |
32 |
Qhov tis ntawm hlau tais |
Teeb ntawm 12 qhov. Txhua txheej ntawm cov hlau spout yog ua los ntawm cov khoom siv nyuaj YG6X nrog ib txoj kab uas hla ntawm 8 hli thiab tsau nrog cov kua nplaum kom ruaj khov kho. |
|||
|
33 |
Pre deformation apparatus |
Bayonet installation yog tshwj tseg thiab kho raws li cov khoom tsim tshwj xeeb |
||||
|
34 |
Kaw lub kaum sab xis ntawm nias tuag |
25 degree los yog tsawg dua |
||||
|
35 |
Xovxwm kab tuag yas dhos qauv |
Lub siab lub caij nplooj ntoos hlav adjusts lub siab |
||||
|
36 |
Nias tuag loj |
100 * 50 * (25 plus 25) L * W * H (qhov siab: loj 50 tom qab ob daim raug kaw) |
Tau customized |
|||
|
37 |
Pwm puag mobile |
Txoj kab nias tuag ncej txais dovetail zawj qhia kev tsheb nqaj hlau los kho thiab txav mus tau yooj yim |
||||
|
38 |
Tom qab deformer |
Customize raws li cov khoom qauv specifications |
||||
|
tuav lub log |
39 |
traction |
Hluav taws xob tswj synchronization |
|||
|
40 |
Traction log txoj kab uas hla mm |
460 * 2 ￠ |
||||
|
41 |
Traction log hom groove / dav hlau hom |
Ua groov |
||||
|
42 |
Traction wheel support system |
Cov kabmob txhawb nqa |
||||
|
43 |
Number of slots/Slot diameter |
Tshooj 8 txog 9 / R3mm |
||||
|
44 |
Qhov hardness |
Traction log khoom GCr15, hardness Ntau dua los yog sib npaug rau HRC58-60o |
||||
|
45 |
Lub realization ntawm twist nrug transformation |
PLC infinite variable ceev |
||||
|
46 |
Qhov ntsuas ntsuas |
Ib qho kawg ntawm lub log traction yog ze rau lub ntsuas ntsuas |
||||
|
47 |
Electronic meter 'meter' ntaus ntawv |
PLC hluav taws xob ntsuas, tso rau ntawm qhov screen |
||||
|
48 |
Tsav txoj kev |
Ib leeg nquag thiab ob lub log traction |
||||
|
Kaw kab kab |
49 |
Ribbon kab |
Servo lub cev muaj zog tswj |
|||
|
50 |
Kab txav hom |
Pob ntsia hlau kab, PLC tswj kev thim rov qab |
||||
|
51 |
Vertical / kab rov tav regulating log |
Cov menyuam muaj R groove, bearing steel |
||||
|
52 |
Kaw kab kev them nyiaj yug |
Txais i-wheel txais txhua yam pneumatic sab saum toj hom |
||||
|
53 |
Siv zog |
Sib nqus hmoov clutch tas li nro retracting. |
||||
|
54 |
Qhov loj ntawm qhov tau txais I-log (mm) |
Cov neeg siv khoom muab |
||||
|
Tsav dynamic Department of system / hluav taws xob tswj |
55 |
kis tau tus mob |
Tsis muaj |
|||
|
56 |
Tus tswv tsev tsav tsheb |
Lub cev muaj zog tsav lub tog raj kheej kom tig |
||||
|
57 |
Main lub cev muaj zog |
Lub cev muaj zog (18.5kW) |
||||
|
58 |
traction |
zaus conversion motor |
||||
|
59 |
Siv lub cev muaj zog |
zaus conversion motor |
||||
|
60 |
Main cav ceev tswj |
Lub inverter |
||||
|
61 |
Ua tiav tshuab hluav taws xob tswj |
PLC tswj qhov program |
||||
|
62 |
tso saib |
Kov npo |
||||
Product Description:
Dav siv nyob rau hauv nruab nrab-loj coils xws li rectifiers, solenoid li qub, thiab high-power transformers.
Txais yuav Taiwan maub los nrog zaus hloov pauv thiab AC lub cev muaj zog kom ua tiav lub suab qis thiab kev saib xyuas dawb.
Multi-function microcomputer tsim, cov ntaub ntawv yooj yim teeb tsa, khaws cia ruaj khov, thiab tsis siv neeg ceev txwv, kho thaum lub sijhawm ncua, ncua sijhawm ntawm ob qho kawg thiab lwm yam haujlwm.
Koj tuaj yeem hloov qhov kev pab cuam kom ua tiav ntau txoj haujlwm raws li koj xav tau.
Lub hwj chim muab hluav taws xob tau txais kev txhim kho los tiv thaiv kev cuam tshuam Circuit Court nrog muaj zog tiv thaiv kev cuam tshuam.
Txoj hauj lwm ntawm lub bobbin tuaj yeem tsim nrog kev qhia ua haujlwm, uas tuaj yeem pab qhov teeb tsa ntawm qhov chaw winding thiab qhov dav ntawm txoj haujlwm.
0~999 pawg ntawm cov kauj ruam yooj yim los teeb. Nrog lub cev muaj zog AC lub cev muaj zog thiab precision stepper lub cev muaj zog, nws tuaj yeem yooj yim teeb tsa rau pem hauv ntej thiab thim rov qab, hla qhov txuas thiab ntws-dense winding ua haujlwm.
Loj torque, loj hloov pauv, yuav khoom sib nqus damping nro hlau khib, qhov nro yog ruaj khov dua. Qhov siab tshaj plaws txoj kab uas hla ntawm 3.0mm tuaj yeem raug mob;
Lengthening layout tuaj yeem xaiv tau, thiab qhov siab tshaj plaws layout dav tuaj yeem yog 1500mm.
